1037

ENGINE (CC)

236

WEIGHT (KG) ABS Model

THE MASTER OF ADVENTURE

Let’s you freely escape into the wilderness and explore to your heart’s content.

A sleek look with the latest features allows for a smooth and comfortable ride.

Limitless potential to continue your adventure.

Ride on my friend.

The new generation V-STROM 1050/XT is always by your side.

EXPLORATION HAS NO LIMITS.

DESIGN IS IN OUR DNA

New Styling

The distinctive styling incorporates elements of both Suzuki’s legendary DR-Z desert racer and the large off-road model DR-BIG. The characteristic beak design first adopted by Suzuki stays true to Suzuki’s heritage while also further evolving the design to be more aggressive and bolder for the new generation V-STROM.

download brochure


DURABLE TWIN-SPAR ALUMINUIM FRAME

The lightweight cast aluminium twin-spar frame realizes the optimal rigidity balance for stability and handling performance. The swingarm is also aluminium supporting the balance and light handling.



ACCESSORIES

USB Outlet: A USB port is located left side of the meter panel. Height Adjustable & Windscreen: The windscreen reduces fatigue when riding at high speeds. Height is adjustable on the V-STROM 1050XT without any tools. Comfortable Seat: The seat has a front/rear separate design and is just the right firmness to provide a comfortable ride with less fatigue even on long rides. Aluminium Tapered Handlebars: The new model is equipped with aluminium tapered handlebars.

ADJUSTABLE SUSPENSION

With an inner tube diameter of only 43mm, the spring preload and compression/rebound damping of the KYB inverted front forks can be fully adjusted, allowing the suspension to be set based on the preference of the rider or the usage conditions. The rear suspension is a bottom link type mono-shock, and the preload can be adjusted simply by turning the dial by hand.

download brochure

SPECIFICATIONS

DIMENSIONS AND WEIGHTS

Oveall length 2,265mm
Overall width 940mm
Overall height 1,465mm
Wheelbase 1,555mm
Ground clearance 160mm
Seat height 850mm
Curb mass 247kg

ENGINE SPECIFICATIONS

Engine type 4-stroke, 2-cylinder, liquid-cooled, DOHC
Bore x Stroke 100.0 mm x 66.0 mm
Engine displacement 1,037 cm³
Compression ratio 11.5:1
Transmission 6-speed constant mesh
Fuel tank 20.0L

CHASSIS SPECIFICATIONS

Suspension Front Inverted telescopic, coil spring, oil damped
Rear Link type, coil spring, oil damped
Brakes Front Disc brake
Rear Disc
Tyres Front 110/80R19M/C 59V, tubeless
Rear 150/70R17M/C 69V, tubeless
